Exception Handling

screenshot of the app

Spring Boot provides us tools to handle exceptions beyond simple ‘try-catch' blocks. To use these tools, we apply a couple of annotations that allow us to treat exception handling as a cross-cutting concern:

  • @ResponseStatus
  • @ExceptionHandler
  • @ControllerAdvice or @RestControllerAdvice

Before Jumping into the above annotations lets see the challenges with SpringBoot Default Exception Handling.

Types of Errors in APIs

  • Client Errors (4xx): Issues with user input. Example: 400 Bad Request, 404 Not Found.
  • Server Errors (5xx): Issues within the server. Example: 500 Internal Server Error.
  • Validation Errors: Missing or invalid fields in a request.

For any exception, SpringBoot provides default error like 400 or 500 based on the scenario.

{
    "timestamp": "2019-11-26T21:54:27.957+00:00",
    "status": 400,
    "error": "Bad Request",
    "path": "/api/v1_0/employees"
}
{
  "timestamp": "2019-11-26T21:59:27.957+00:00",
  "status": 500,
  "error": "Internal Server Error",
  "message": "",
 "path": "/api/v1_0/employees/search/Praveen"
}

Standardizing API Error Responses

A well-structured error response helps clients handle errors effectively

Now lets fix this by creating GlobalExceptionHandler Class

package com.praveen.employee.controller.advice;


import com.google.common.collect.Maps;
import com.praveen.employee.bo.EmployeeResponse;
import com.praveen.employee.bo.ErrorMessage;
import com.praveen.employee.bo.ValidationError;
import com.praveen.employee.common.Constants;
import com.praveen.employee.config.AppConfig;
import com.praveen.employee.exception.EmployeeNotFoundException;
import com.praveen.employee.filters.InputRequestContextHolder;
import jakarta.validation.ConstraintViolationException;
import org.apache.commons.lang3.StringUtils;
import org.apache.commons.text.StringSubstitutor;
import org.hibernate.validator.internal.engine.path.PathImpl;
import org.slf4j.Logger;
import org.slf4j.LoggerFactory;
import org.springframework.http.HttpStatus;
import org.springframework.http.ResponseEntity;
import org.springframework.http.converter.HttpMessageNotReadableException;
import org.springframework.validation.FieldError;
import org.springframework.validation.ObjectError;
import org.springframework.web.HttpRequestMethodNotSupportedException;
import org.springframework.web.bind.MethodArgumentNotValidException;
import org.springframework.web.bind.annotation.ExceptionHandler;
import org.springframework.web.bind.annotation.RestControllerAdvice;

import java.util.List;
import java.util.Map;

@RestControllerAdvice
public class GlobalExceptionHandler {

    private static final Logger log = LoggerFactory.getLogger(GlobalExceptionHandler.class);

    private final AppConfig applicationConfig;

    public GlobalExceptionHandler(AppConfig applicationConfig) {
        this.applicationConfig = applicationConfig;
    }

    @ExceptionHandler(HttpMessageNotReadableException.class)
    public ResponseEntity<EmployeeResponse> handleHttpMessageNotReadableException() {
        Map<String, String> validationErrors = Maps.newHashMap();
        validationErrors.put(applicationConfig.getMessageNotReadableError().code(),
                applicationConfig.getMessageNotReadableError().description());
        EmployeeResponse empResponse = new EmployeeResponse(Constants.FAIL,
                InputRequestContextHolder.getTransactionId(), null,
                new ErrorMessage(applicationConfig.getClientError().code(),
                        applicationConfig.getClientError().description(), validationErrors));
        return errorResponse(HttpStatus.BAD_REQUEST, empResponse);

    }

    @ExceptionHandler(HttpRequestMethodNotSupportedException.class)
    public ResponseEntity<EmployeeResponse> handleHttpMethodNotAllowedException() {
        Map<String, String> validationErrors = Maps.newHashMap();
        validationErrors.put(applicationConfig.getInvalidHttpMethodError().code(),
                applicationConfig.getInvalidHttpMethodError().description());
        EmployeeResponse empResponse = new EmployeeResponse(Constants.FAIL,
                InputRequestContextHolder.getTransactionId(), null,
                new ErrorMessage(applicationConfig.getClientError().code(),
                        applicationConfig.getClientError().description(), validationErrors));
        return errorResponse(HttpStatus.METHOD_NOT_ALLOWED, empResponse);

    }

    @ExceptionHandler(ConstraintViolationException.class)
    public ResponseEntity<EmployeeResponse> handleValidationErrors(
            ConstraintViolationException constraintViolationException) {
        Map<String, String> validationErrors = Maps.newHashMap();
        constraintViolationException.getConstraintViolations().forEach(violationErrors -> {
            String field = ((PathImpl) violationErrors.getPropertyPath()).getLeafNode().asString().trim();
            List<ValidationError> validationErrorList = applicationConfig.getValidationErrors().get(field.trim());
            validationErrorList.forEach(validationError -> validationErrors.put(validationError.code(),
                    replaceTemplateValues(validationError.description(), field.trim())));
        });

        EmployeeResponse empResponse = new EmployeeResponse(Constants.FAIL,
                InputRequestContextHolder.getTransactionId(), null,
                new ErrorMessage(applicationConfig.getClientError().code(),
                        applicationConfig.getClientError().description(), validationErrors));
        log.error(Constants.INPUT_VALIDATION_ERROR, constraintViolationException, empResponse);


        return errorResponse(HttpStatus.BAD_REQUEST, empResponse);

    }

    @ExceptionHandler(RuntimeException.class)
    public ResponseEntity<EmployeeResponse> handleInternalServerError(RuntimeException exception) {

        Map<String, String> serverErrors = Maps.newHashMap();
        serverErrors.put(applicationConfig.getServerErrors().code(),
                applicationConfig.getServerErrors().description() + " " + exception.getMessage());

        EmployeeResponse empResponse = new EmployeeResponse(Constants.FAIL,
                InputRequestContextHolder.getTransactionId(), null,
                new ErrorMessage(applicationConfig.getServerError().code(),
                        applicationConfig.getServerError().description(), serverErrors));

        log.error(Constants.INTERNAL_SERVICE_ERROR, exception, empResponse);

        return errorResponse(HttpStatus.INTERNAL_SERVER_ERROR, empResponse);

    }

    @ExceptionHandler(MethodArgumentNotValidException.class)
    public ResponseEntity<EmployeeResponse> handleClientErrors(
            MethodArgumentNotValidException methodArgumentNotValidException) {
        Map<String, String> validationErrors = Maps.newHashMap();
        if (methodArgumentNotValidException.getBindingResult().getGlobalError() != null) {
            populateGlobalError(validationErrors, methodArgumentNotValidException.getBindingResult().getGlobalError());
        }
        methodArgumentNotValidException.getBindingResult().getFieldErrors()
                .forEach(fieldError -> populateValidationErrors(validationErrors, fieldError));

        EmployeeResponse empResponse = new EmployeeResponse(Constants.FAIL,
                InputRequestContextHolder.getTransactionId(), null,
                new ErrorMessage(applicationConfig.getClientError().code(),
                        applicationConfig.getClientError().description(), validationErrors));


        log.error(Constants.INPUT_VALIDATION_ERROR, methodArgumentNotValidException, empResponse);

        return errorResponse(HttpStatus.BAD_REQUEST, empResponse);
    }

    @ExceptionHandler(EmployeeNotFoundException.class)
    public ResponseEntity<EmployeeResponse> handleEmployeeNotFound(
            EmployeeNotFoundException employeeNotFoundException) {

        Map<String, String> validationErrors = Maps.newHashMap();
        validationErrors.put("40010", "Employee Not Found");

        EmployeeResponse empResponse = new EmployeeResponse(Constants.FAIL,
                InputRequestContextHolder.getTransactionId(), null,
                new ErrorMessage("4000", "Input Validation Failure", validationErrors));

        log.error(Constants.INPUT_VALIDATION_ERROR, employeeNotFoundException, empResponse);

        return errorResponse(HttpStatus.BAD_REQUEST, empResponse);

    }

    private void populateValidationErrors(Map<String, String> validationErrors, FieldError fieldError) {
        String fieldName = deriveFieldName(fieldError);
        List<ValidationError> validationErrorsList = applicationConfig.getValidationErrors().get(fieldName);
        validationErrorsList.forEach(validationError -> validationErrors.put(validationError.code(),
                replaceTemplateValues(validationError.description(), fieldName)));
    }

    private String deriveFieldName(FieldError fieldError) {
        String fieldName = fieldError.getField();
        if (fieldName.contains(".")) {
            fieldName = StringUtils.substringAfter(fieldName, ".");
        }
        return fieldName;
    }

    private void populateGlobalError(Map<String, String> validationErrors, ObjectError fieldError) {

        List<ValidationError> validationErrorsList = applicationConfig.getValidationErrors()
                .get(fieldError.getDefaultMessage());
        validationErrorsList.forEach(validationError -> validationErrors.put(validationError.code(),
                replaceTemplateValues(validationError.description(), fieldError.getDefaultMessage())));

    }

    private String replaceTemplateValues(String templateMessage, String fieldName) {
        Map<String, String> validationOverrides = Maps.newHashMap();
        if (StringUtils.equalsIgnoreCase("appId", fieldName)) {
            validationOverrides.put("appIds", StringUtils.join(applicationConfig.getAppIds()));
        }
        StringSubstitutor sub = new StringSubstitutor(validationOverrides);
        return sub.replace(templateMessage);
    }

    private ResponseEntity<EmployeeResponse> errorResponse(HttpStatus status, EmployeeResponse empResponse) {
        return ResponseEntity.status(status).body(empResponse);
    }

}

Controller

package com.praveen.employee.controller;

import com.praveen.employee.aop.LoggingAspect;
import com.praveen.employee.aop.TrackExecutionTime;
import com.praveen.employee.bo.EmployeeRequest;
import com.praveen.employee.bo.EmployeeResponse;
import com.praveen.employee.entity.Employee;
import com.praveen.employee.exception.EmployeeNotFoundException;
import com.praveen.employee.service.EmployeeManagementService;
import io.swagger.v3.oas.annotations.Operation;
import io.swagger.v3.oas.annotations.tags.Tag;
import jakarta.validation.Valid;
import jakarta.validation.constraints.Min;
import jakarta.validation.constraints.NotBlank;
import jakarta.validation.constraints.Size;
import org.springframework.http.MediaType;
import org.springframework.validation.annotation.Validated;
import org.springframework.web.bind.annotation.*;

import java.util.List;

@RestController
@Validated
@RequestMapping("/api/v1")
@Tag(description = "Employee Management Operations", name = "Employee Management Operations")
public class EmployeeManagementController {

    private final EmployeeManagementService employeeManagementService;

    public EmployeeManagementController(EmployeeManagementService employeeManagementService) {
        this.employeeManagementService = employeeManagementService;
    }

    @GetMapping(value = "/employees", produces = MediaType.APPLICATION_JSON_VALUE)
    @LoggingAspect
    @TrackExecutionTime
    @Operation(description = "Fetch All Employees", summary = "Fetch All Employees")
    public List<Employee> fetchAllEmployees() {
        return employeeManagementService.fetchAllEmployees();

    }

    @GetMapping(value = "/employees/search", produces = MediaType.APPLICATION_JSON_VALUE)
    @LoggingAspect
    @TrackExecutionTime
    @Operation(description = "Fetch Employee by Employee Name", summary = "Fetch Employee by Employee Name")
    public List<Employee> getEmployeeByName(@RequestParam @NotBlank @Size(min = 5) String name) {
        return employeeManagementService.getEmployeeByName(name);

    }

    @GetMapping(value = "/employees/search/location/{location}", produces = MediaType.APPLICATION_JSON_VALUE)
    @LoggingAspect
    @TrackExecutionTime
    @Operation(description = "Fetch Employee by Location", summary = "Fetch Employee by Location")
    public List<Employee> getEmployeeByLocation(@PathVariable @NotBlank String location) {
        return employeeManagementService.getEmployeeByLocation(location);

    }

    @GetMapping(value = "/employees/{id}", produces = MediaType.APPLICATION_JSON_VALUE)
    @LoggingAspect
    @TrackExecutionTime
    @Operation(description = "Fetch Employee By Employee Id", summary = "Fetch Employee By Employee Id")
    public EmployeeResponse getEmployeeById(@PathVariable @Min(1) Long id) throws EmployeeNotFoundException {
        return employeeManagementService.getEmployeeById(id);
    }

    @PostMapping(value = "/employees", produces = MediaType.APPLICATION_JSON_VALUE, consumes = MediaType.APPLICATION_JSON_VALUE)
    @LoggingAspect
    @TrackExecutionTime
    @Operation(description = "Create Employee", summary = "Create Employee")
    public EmployeeResponse createEmployee(@RequestBody @Valid EmployeeRequest emp) {
        return employeeManagementService.createEmployee(emp);
    }

    @PutMapping(value = "/employees/{id}", produces = MediaType.APPLICATION_JSON_VALUE, consumes = MediaType.APPLICATION_JSON_VALUE)
    @LoggingAspect
    @TrackExecutionTime
    @Operation(description = "Create Employee", summary = "Create Employee")
    public EmployeeResponse updateEmployeeById(@RequestBody @Valid EmployeeRequest emp, @PathVariable @Min(1) Long id)
            throws EmployeeNotFoundException {
        return employeeManagementService.updateEmployeeById(emp, id);
    }

    @DeleteMapping(value = "/employees/{id}", produces = MediaType.APPLICATION_JSON_VALUE)
    @LoggingAspect
    @TrackExecutionTime
    @Operation(description = "Delete Employee By Employee Id", summary = "Delete Employee By Employee Id")
    public EmployeeResponse deleteEmployeeById(@PathVariable @Min(1) Long id) {
        return employeeManagementService.deleteEmployeeById(id);
    }

}

BO

package com.praveen.employee.bo;

import com.praveen.employee.validators.AppId;

import jakarta.validation.constraints.Digits;
import jakarta.validation.constraints.NotEmpty;
import jakarta.validation.constraints.NotNull;
import jakarta.validation.constraints.Size;

public record EmployeeRequest(@AppId @NotNull String appId, @NotEmpty @Size(min = 0, max = 20) String transactionId,
		@NotEmpty @Size(min = 0, max = 20) String name, @NotEmpty @Size(min = 0, max = 20) String designation,
		@Digits(fraction = 2, integer = 25) Long salary, @NotEmpty @Size(min = 0, max = 20) String location) {
}


package com.praveen.employee.bo;

public record EmployeeResponse(String status, String transactionId, String appId, EmployeeResponseData data,
		ErrorMessage errors) {
}


package com.praveen.employee.bo;

public record EmployeeResponseData(Long id, String name, String designation, Long salary, String location) {
}


package com.praveen.employee.bo;

import java.util.Map;

import io.swagger.v3.oas.annotations.media.Schema;

@Schema(name = "ErrorMessage", example = "Error Details to describe the Client, Business and System Errors")
public record ErrorMessage(@Schema(name = "code", description = "4000,6000,5000", example = "4000") String code,
		@Schema(name = "description", description = "Input Request Validation Failure and Internal Service Failures", example = "Input Request Validation Failure") String description,
		@Schema(name = "errors", example = "{\"400001\":\"Request Json is malformed or invalid\"}") Map<String, String> errors) {
}


package com.praveen.employee.bo;

public record ValidationError(String code, String description) {
}


package com.praveen.employee.bo;

public record CommonError(String code, String description) {
}

application.yml

 spring:
  application:
    name: emp-mgmt-service
  datasource:
    url: jdbc:postgresql://localhost:5432/praveenoruganti
    username: postgres
    password: praveen
    hikari:
      minimum-idle: 5
      maximum-pool-size: 10
  jpa:
    hibernate:
      ddl-auto: update
    show-sql: true
    format-sql: true

springdoc:
   use-fqn: true
   swagger-ui:
    doc-expansion: none
    operationsSorter: method
#   supportedSubmitMethods: []

logging:
  structured:
    format:
      console: ecs

app:
 openApiTitle: Employee Management Service
 openApiDescription: |

       Employee Management Service is used to manage employees.

 validationErrors:
   id:
     - code: 400010
       description: Invalid Employee Id
   name:
     - code: 400004
       description: Invalid Name
   transactionId:
     - code: 400005
       description: Invalid Transaction Id and max length should be less then 20
   appId:
     - code: 400006
       description: Invalid App ID
   salary:
     - code: 400007
       description: Invalid Salary Amount and it needs to be with 2 decimals max
   designation:
     - code: 400008
       description: Invalid Designation
   location:
     - code: 400009
       description: Invalid Location
 messageNotReadableError:
     code: 400001
     description: Request Json is malformed or invalid
 invalidHttpMethodError:
     code: 400002
     description:  Request Method is not allowed
 invalidInputError:
     code: 400003
     description:  Dynamic Content type not supported
 clientError:
    code: 4000
    description: Input Validation Failure
 businessError:
    code: 6000
    description: Business Validation Failure
 serverError:
    code: 5000
    description: Internal Server Error
 serverErrors:
    code: 500001
    description: Unable to process the request. Please contact support team.

Lets try out some scenarios,

  • Success
{
  "status": "Success",
  "transactionId": "bf663c80-bf34-4fe1-a961-8b581dd7d2c1",
  "appId": null,
  "data": {
    "id": 1,
    "name": "Praveen",
    "designation": "Technical Architect",
    "salary": 5000000,
    "location": "Hyderabad"
  },
  "errors": null
}
  • Input validation Failure
{
  "status": "Fail",
  "transactionId": null,
  "appId": null,
  "data": null,
  "errors": {
    "code": "4000",
    "description": "Input Validation Failure",
    "errors": {
      "400005": "Invalid Transaction Id and max length should be less then 20",
      "400006": "Invalid App ID",
      "400009": "Invalid Location"
    }
  }
}
